Specifications

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
7.50R15TR	136/134J	18	6.00	5.50,6.50	215	808	372	2240/4940	2120/4675	830	120	14.0
7.00R16LT	107/102K	8	5.50F	6.00G	200	785	362	975/2150	850/1875	460	67	12.5
7.00R16LT	111/107K	10	5.50F	6.00G	200	775	362	1090/2405	975/2150	560	80	12.5
7.00R16LT	118/114K	14	5.50F	6.00G	200	775	362	1320/2910	1180/2600	770	112	12.5
7.50R16LT	105/101K	6	6.00G	5.50F,6.50H	215	805	375	925/2040	825/1820	350	50	14.0
7.50R16LT	112/107K	8	6.00G	5.50F,6.50H	215	805	375	1120/2470	975/2150	460	65	14.0
7.50R16LT	122/118K	14	6.00G	5.50F,6.50H	215	805	375	1500/3305	1320/2910	770	110	14.0
8.25R16LT	110/105K	6	6.50H	6.00G 6.50	235	865	397	1060/2335	925/2040	320	45	13.0
8.25R16LT	126/112K	14	6.50H	6.00G 6.50	235	865	397	1700/3750	1500/3305	170	97	13.0
8.25R16LT	128/124K	16	6.50H	6.00G 6.50	235	855	397	1800/3970	1600/3525	770	112	13.0
9.00R20	141/139K	14	7.00	7.00T,7.50	259	1019	471	2575/5675	2430/5355	790	115	15.5
9.00R20	144/142K	16	7.00	7.00T,7.50	259	1019	471	2800/6175	2650/5840	900	130	15.5
10.00R20	146/143K	16	7.50	7.50V,8.00	278	1054	486	3000/6610	2725/6005	830	120	16.5
10.00R20	149/146K	18	7.50	7.50V,8.00	278	1054	486	3250/7160	3000/6610	930	135	16.5
11.00R20	150/147K	16	8.00	8.50,8.00V	293	1085	499	3350/7390	3075/6780	830	120	17.5
11.00R20	152/149K	18	8.00	8.50,8.00V	293	1085	499	3550/7830	3250/7160	930	135	17.5
12.00R20	152/149K	16	8.50	8.50V,9.00	315	1125	516	3550/7830	3250/7160	760	110	18.5
12.00R20	154/151K	18	8.50	8.50V,9.00	315	1125	516	3750/8270	3450/7610	830	120	18.5
12.00R20	156/153G	20	8.50	8.50V,9.00	315	1125	516	4000/8820	3650/8050	900	131	18.5
12.00R20	158/155F	22	8.50	8.50V,9.00	315	1125	516	4250/9370	3875/8540	970	141	18.5
11R22.5	144/142M	14	8.25	7.50	279	1054	491	2800/6175	2650/5840	720	105	22.5
11R22.5	146/143M	16	8.25	7.50	279	1054	491	3000/6610	2725/6005	830	120	22.5

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
8.25R16LT	128/124K	16	6.50H	6.00G,6.50	235	855	397	1800/3970	1600/3520	770	112	16.5
8.25R20	129/127K	10	6.5	6.50T,7.00,7.00T	236	986	452	1850/4080	1750/3860	620	90	16.5
8.25R20	139/137K	16	6.5	6.50T,7.00,7.00T	236	974	452	2430/5355	2300/5070	930	135	16.5
9.00R20	141/139J	14	7	7.00T,7.50	259	1019	471	2575/5675	2430/5355	790	115	18
9.00R20	144/142J	16	7	7.00T,7.50	259	1019	471	2800/6175	2650/5840	900	130	18
10.00R20	146/143J	16	7.5	7.50V,8.00	278	1054	486	3000/6610	2725/6005	830	120	19.5
10.00R20	149/146J	18	7.5	7.50V,8.00	278	1054	486	3250/7160	3000/6610	930	135	19.5
10.00R20	149/146K	18	7.5	7.50V,8.00	278	1054	486	3250/7160	3000/6610	930	135	19.5
11.00R20	150/147J	16	8	8.50,8.00V	293	1085	499	3350/7390	3075/6780	830	120	21
11.00R20	152/149J	18	8	8.50,8.00V	293	1085	499	3550/7830	3250/7160	930	135	21
12.00R20	154/151J	18	8.5	8.50V,9.00	315	1125	516	3750/8270	3450/7610	830	120	21
12.00R20	156/153G	20	8.5	8.50V,9.00	315	1125	516	4000/8820	3650/8050	900	131	21
12.00R20	158/155F	22	8.5	8.50V,9.00	315	1125	516	4250/9370	3875/8540	970	141	21
12R22.5	150/147L	16	9	8.25	300	1085	504	3350/7390	3075/6780	830	120	21
12R22.5	152/149K	18	9	8.25	300	1085	504	3550/7830	3250/7160	930	135	21

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
12.00R24	158/155K	18	8.5	8.50V,9.00	315	1238	572	4250/9370	3875/8540	830	120	18.5
12.00R24	160/157J	20	8.5	8.50V,9.00	315	1238	572	4500/9920	4125/9094	900	131	18.5
12.00R24	160/157K	20	8.5	8.50V,9.00	315	1238	572	4500/9920	4125/9094	900	131	18.5
