Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
11R22.5	144/142M	14	8.25	7.5	279	1054	491	2800/6175	2650/5840	720	105	11
11R22.5	146/143M	16	8.25	7.5	279	1054	491	3000/6610	2725/6005	830	120	11
12R22.5	150/147L	16	9	8.25	300	1085	504	3350/7390	3075/6780	830	120	16
12R22.5	152/149K	18	9	8.25	300	1085	504	3550/7830	3250/7160	930	135	16
11R24.5	146/143M	14	8.25	7.5	279	1104	516	3000/6610	2725/6005	720	105	11
11R24.5	149/146M	16	8.25	7.5	279	1104	516	3250/7160	3000/6610	830	120	11
295/75R22.5	144/141M	14	9	8.25	298	1014	474	2800/6175	2575/5675	760	110	11
285/75R24.5	144/141M	14	8.25	—	283	1050	493	2800/6175	2575/5675	760	110	11
285/75R24.5	147/144L	16	8.25	—	283	1050	493	3075/6780	2800/6175	830	120	11
255/70R22.5	140/137M	16	7.5	8.25	255	930	435	2500/5510	2300/5070	830	120	13

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
ST235/80R16	129/125L	14	6 1/2 J	6J,7J,6K,7K, 6L,7L,6 1/2J, 7 1/2J,6 1/2L	235	782	—	1850/4080	1650/3640	760	110	8.5
ST235/85R16	132/127L	14	6 1/2 J	6J,7J,6K,7K, 6L,7L,6 1/2J, 7 1/2J,6 1/2L	235	806	—	2000/4400	1750/3860	760	110	10.5
