Specifications

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
295/80R22.5	152/148M	16	9	8.25	298	1044	487	3550/7825	3150/6945	850	125	18
295/80R22.5	152/148M	16	9	8.25	298	1044	487	3550/7825	3150/6945	850	125	18
295/80R22.5	154/151M	18	9	8.25	298	1044	487	3750/8270	3450/7610	900	130	18
295/80R22.5	154/151M	18	9	8.25	298	1044	487	3750/8270	3450/7610	900	130	18
315/80R22.5	154/151M	18	9	9.75	312	1076	500	3750/8270	3450/7610	830	120	20
315/80R22.5	154/151M	18	9	9.75	312	1076	500	3750/8270	3450/7610	830	120	20
315/80R22.5	157/154L	20	9	9.75	312	1076	500	4125/9090	3750/8270	900	130	20
315/80R22.5	157/154L	20	9	9.75	312	1076	500	4125/9090	3750/8270	900	130	20
285/70R19.5	140/137M	14	8.25	9	283	895	413	2500/5510	2300/5070	760	110	16.5
285/70R19.5	144/142M	16	8.25	9	283	895	413	2800/6175	2650/5840	830	120	16.5
285/70R19.5	146/144L	18	8.25	9	283	895	413	3000/6610	2800/6175	850	123	16.5
285/70R19.5	146/144L	18	8.25	9	283	895	413	3000/6610	2800/6175	850	123	16.5
315/70R22.5	149/146M	16	9	9.75	312	1014	469	3250/7160	3000/6610	760	110	16
315/70R22.5	151/148M	18	9	9.75	312	1014	469	3450/7610	3150/6940	830	120	16
315/70R22.5	152/148M	16	9	9.75	312	1014	469	3550/7830	3150/6940	830	120	16
315/70R22.5	152/148M	16	9	9.75	312	1014	469	3550/7830	3150/6940	830	120	16

Size	LI/SS	PR	Rim size	Rim allowance	Inflated Section width mm	Overall diameter mm	Radius under load mm	Load capacity kg/lbs		IP		OTD mm
								Single	Dual	kpa	Psi
12R22.5	150/147L	16	9	8.25	300	1085	504	3550/7390	3075/6780	830	120	23
12R22.5	152/149K	18	9	8.25	300	1085	504	3550/7830	3250/7160	930	135	23
